ART Midrange

360 degrees high-resolution fast-scan surveillance radar

ART Midrange is a high-resolution surveillance radar system designed to address the demands of the Security and Defense market in two key applications: unregulated border surveillance and critical infrastructure protection. This high-resolution radar detects and tracks individuals and vehicles before, during and eventually after the trespassing of national borders or during their approach to the security perimeter of critical infrastructure installations. ART Midrange also detects and tracks emerging threats such as micro drones and UAVs.

This state-of-the-art radar sensor can be complemented with electro-optical platforms, countermeasure devices and ART HMI Multi-sensor Command and Control Software, to obtain an industry leading integrated solution. The combination of these elements provides complete situational awareness in complex real-life environments.

Coverage

Complete 360º coverage with a single unit (wide area surveillance >78 km²).

Update Rate

Fast 1 Hz scan rate in all operational modes providing early target confirmation.

Detection Performance

State-of-the-art detection range for UAV's, personnel and light vehicles. Detectable target RCS below 0.01 m².

Technology

Continuous wave linear frequency modulated radar with inherent LPI characteristics.

Highlights

Build a cost-effective early warning solution

ART Midrange enhances the performance of traditional camera-based surveillance systems in a cost-effective manner, incorporating the advantages of radar-based target detection and tracking.

Integration-ready for comprehensive security

ART Midrange is a network-centric device designed for seamless integration with industry-standard protocols, making it easy to incorporate the benefits of radar technology into any existing surveillance solution.

Leverage a decade of proven expertise

Backed by more than a decade of proven expertise, ART Midrange benefits from a globally deployed family of radar systems, sharing robust subsystems and extensively field-proven components.

Applications

Border surveillance

Critical asset protection

Force protection

C-UAS

ART Midrange

Waveform	Wideband coherent Doppler CWLFM Low Probability of Interception (LPI)
Frequency band	Ku Band
Transmitter type	Solid state
RF transmission masking	Configurable RF transmission azimuth sectors
Processing	Coherent integration - Doppler processing Adaptive clutter map Track-before-declare Built-in multi target tracker
Scan speed	60 RPM
Instrumental detection range	10, 7 or 5 km

Technologies

Compact single unit with 360° coverage and fast scan rate
Direct measurement of target altitude
Small target detection better than 0.01 m² RCS
Low operation workload, automatic adaptation to the environment
High range accuracy and resolution
Target classification
SAPIENT C-UAS standard & ASTERIX compliant

ART R&D Team has a broad scope of research and engineering background that results in an extensive range of cutting edge capabilities.
